| Technical Specifications:- SpeedyBee Fold 8 DC Long Range Drone Frame | |
|---|---|
| Product Name | SpeedyBee Fold 8 DC Long Range Drone |
| Wheelbase | DC Fold: 360 mm | Front: 305 mm | Rear: 272 mm |
| Weight | MARIO Fold 8 DC O3 Kit: 695 g |
| Top Plate Thickness | 2.5 mm (T300 3K) |
| Middle Plate Thickness | 2.5 mm (T300 3K) |
| Bottom Plate Thickness | 3 mm (T300 3K) |
| Arm Thickness | 7 mm (T300 3K) |
| Camera Screw | 7 mm |
| 3D Printed Part | Yellow TPU |
| Stack Side Plate | PC |
| Battery Anti-Skid Mat | Silicone Resin |
| Motor Circlip Spacing | 9 mm |
| Propellers | 7-8 Inch |
| Motor Mounting Holes | 19 mm |
| FC Mounting Hole | 30.5 × 30.5 mm (M3) & 20 × 20 mm (M3) |
| Drone Head | 7075 CNC Aluminum Alloy |
| Aluminum Standoff | 7075 M3 × 22 mm (5 mm & 4.6 mm) |
| Internal Installation Height | 22-31 mm |
| Antenna Mounting | SMA OR O3 Ant CNC GPS: 25 × 25 × 8 mm |
