This heat shrink has exceptional insulation characteristics, excellent stress control properties; long-term weather and regular wear and tear resistance, ease of installation and reliable performance in even in harshest of situations. These High performance 2:1 heat shrink material tubes, bundles, and protects cables; wire and hoses are used for a wide range of DIY applications. It is used extensively for cable and wire harnessing, strain relief, insulation, color-coding, identification, and protection. Simply a great way to create a Flexible, Heat Resistant, and Waterproof tight joint. Just slide a slightly larger tube at the desired location and apply heat through a cigarette lighter, or a heat gun; for about 10 seconds and the tube will shrink down and will hold the joint tightly.
A Heat Shrink Sleeve measuring 2mm in width and 1 meter in length, and coming in a black color, is a specialized electrical and wire management accessory. These sleeves are designed to provide insulation, protection, and organization for wires, cables, and electronic components while also offering a discreet and professional appearance. Here’s a description of a typical 2mm black heat shrink sleeve and its key features:
Description: A Heat Shrink Sleeve is a cylindrical tube made from a specialized polymer material that shrinks when exposed to heat. The “2mm” dimension refers to the initial diameter of the sleeve before it is heated and shrunk down to its final size. The “1 meter” length indicates the total length of the sleeve. The “black” color means that the sleeve is black in color, which can be particularly useful for concealing wires and creating a clean, finished look.
Features:
- Heat-Activated Shrinkage: The key feature of this sleeve is its ability to shrink when heat is applied. This allows it to tightly conform to the shape of the component or wire it covers, providing a secure and protective covering.
- Black Color: The black color of the sleeve is often chosen for its discreet appearance. It can blend well with the surroundings and help conceal wires or components, making it ideal for applications where aesthetics and camouflage are important.
- Insulation: Heat shrink sleeves provide electrical insulation, helping to prevent short circuits or electrical leaks. They also protect against moisture, dust, and contaminants.
- Abrasion Resistance: The sleeve adds an extra layer of protection against abrasion and mechanical damage, extending the lifespan of wires and cables.
- Versatility: It can be used for various wire management applications, including splicing, bundling, and covering connectors. It’s suitable for both low-voltage and high-voltage applications.
- Temperature Range: Heat shrink sleeves are designed to withstand a wide range of temperatures, making them suitable for use in different environments and conditions.
- Easy Installation: Using a heat source, such as a heat gun or torch, the sleeve is heated until it shrinks and adheres tightly to the component it’s covering. Installation is relatively simple and can be done with minimal tools.
- Durable Material: The sleeves are typically made from a durable, flame-resistant, and chemically stable material like polyolefin or PVC.
- Length and Diameter Options: Heat shrink sleeves are available in various lengths and diameters to suit different wire or component sizes and project requirements.
- Adhesive-Lined Options: Some heat shrink sleeves have an inner adhesive lining that creates a watertight seal when shrunk. This is especially useful for outdoor or marine applications.
- Compliance: High-quality heat shrink sleeves may meet industry standards for electrical and environmental protection, ensuring safety and reliability.
Heat shrink sleeves, especially those in black, are commonly used in automotive, aerospace, electrical, and electronic applications, as well as in DIY projects where a clean, inconspicuous appearance is desired. They offer a cost-effective and reliable solution for protecting and organizing wires and cables while maintaining electrical integrity and visual aesthetics. Proper installation and sizing are important to ensure the desired level of protection and performance.
Package Includes:
1x Heat Shrink Sleeve 2mm Black 1meter
Specification:
Item Type: | CB-HFT |
Color: | Black |
Diameter (mm): | 2 |
Length (mm): | 3000 |
Shrink Temperature (°C) | 90 |
Operating Temperature (°C) | -40 to 125 |
Tensile Strength (MPa): | ≥10.4 |
Shrink Ratio: | 2:01 |
Elongation Ratio | ≥200% |
Radial Shrinking Ratio | ≥50% |
Dielectric Strength | ≥15 kV/mm |
Corrosion of Bare Copper | No Corrosion |
Heat Shock | No Cracking |
Cold Bend | No Cracking |
Flammability | VW-1 |
Concentricity | ≥65% |
Shipping Weight | 0.08 kg |
Shipping Dimensions | 6 × 4 × 3 cm |
