| Resolution | 256*192 |
| Frame Rate | 50fps |
| Lens | Fixed Focus Atherma 7mm |
| FOV(H*V) | 25°*19° |
| Refresh Rate | 25Hz |
| Detector Type | 12μm |
| Spectral Range | 8～14μm |
| Thermal Sensitivity | <50mk |
| Image Display | White Hot |
| Image Algorithm | Non-uniformity Correction (NUC); 3D Noise Reduction (3DNR); Digital Detail Enhancement |
| Power Input | 4.5-18V |
| Video Output | CVBS |
| Weight | 28g |
| TV System | PAL |
| Size | 25.8*25.8*31.8mm |
| Consumption | <1W |
| Working Temperature | -40℃～+80℃ |
| Storage Temperature | -50℃～+85℃ |
| Humidity | 5%~95%, Non-condensin |
| Vibration | 6.06grms, 3-axis |
| Shock | Half-sine Wave, 80g/4ms, 3-axis 6-directi |
| Package Includes | 1 x Camera, 1 x Cable, 1 x Bracket |
