This is an Emax ECOII-2004-2000KV Brushless Motor.
The engineers at EMAX are always seeking ways to design the ultimate motor with brushless technology. In their efforts, they produced the ECO II Series, a new line of brushless motors that further improved performance and durability while retaining the same affordability.
Redesigned from the ground up, the ECO II boasts an all-new architecture. Maximum durability is achieved with a more rounded design paired with thicker reinforcements. Finished with a reflective surface, the ECO II offers a sleek modern design destined to satisfy the need for both aesthetics and durability.
To improve the performance of its predecessor, the ECO II utilizes N52SH arc magnets over prior N48 magnets, allowing for a more powerful throttle response and higher RPMs. More torque and thrust are generated, allowing pilots the flexibility to meet the demands of any racetrack or flight situation comfortably.
Features:
- A brand new design with a rounded bell and stronger attachment points for increased durability.
- Fully mirror-polished finish that shines and glistens with even the smallest hint of light.
- Upgraded N52SH curved arc magnets for tighter airgap and better performance.
- Precision NSK bearing for unparalleled smooth operation.
- 12x12mm motor mounting.
Package Includes:
5× M2 x 6mm Screw
5× M2 x 7.5mm Screw
3× M2 x 8.5mm Screw
1× Washer and screw for shaft
Specification:-
| Motor KV (RPM/V) |
2000 |
|---|---|
| Motor Type |
Brushless Motor |
| Framework |
12N14P |
| Stator Diameter |
20 |
| Stator Height |
4 |
| Thread Direction |
Both |
| Maximum Thrust (gm) |
1130G(on 6s) |
| Compatible Prop (inch): |
4"-5" |
| Weight (g): |
16.6g |
| Shipping Weight | 0.036 kg |
| Shipping Dimensions | 7 × 4 × 2 cm |
