This is a 7 Pin JST XH with Cable. It is a multipurpose cable. The length of the cable is 22cm. The crimp-style connector was developed based on the high reliability and versatility of the connectors. These wire-to-board connectors are typically used to bring power to a PC board.

A 7 Pin JST XH 2.54mm Pitch Plug with a cable is a connector assembly commonly used in electronics and electrical applications to establish a secure and reliable connection between components. This type of connector is known for its compatibility with various electronic devices and microcontrollers. Here’s a description and the key features of a 7 Pin JST XH 2.54mm Pitch Plug with cable:

Description: The 7 Pin JST XH 2.54mm Pitch Plug with cable consists of two main components:

1. Plug: The plug is a housing or connector with seven male pins or terminals. These pins are designed to fit into a corresponding female connector or header. The spacing between the pins is 2.54mm (0.1 inches), which is a standard pitch in electronics, making it compatible with various development boards, sensors, and other components.
2. Cable: The cable is attached to the plug and typically consists of seven color-coded wires. The wires are usually made of stranded copper for flexibility and durability. Each wire serves a specific function, and the colors are often standardized for easy identification.

Features:

1. 7 Pins: This connector has seven pins, which means it can accommodate up to seven different electrical connections, making it suitable for a variety of applications where multiple signals or power sources need to be connected.
2. JST XH Connector: The JST XH connector is a well-known and widely used type in the electronics industry. It is known for its reliability and secure connection.
3. 2.54mm Pitch: The 2.54mm (0.1-inch) pitch is a standard spacing in electronics, ensuring compatibility with various development boards, breadboards, and other electronic components.
4. Plug and Play: The plug-and-play design of this connector makes it easy to connect and disconnect components without soldering. This simplifies the assembly and disassembly process in electronic projects.
5. Color-Coded Wires: The cable typically includes color-coded wires, making it easier to identify and connect the appropriate signals. Common color-coding schemes include red for power, black for ground, and other colors for specific signals.
6. Stranded Copper Wires: The use of stranded copper wires in the cable enhances flexibility and durability. Stranded wires are more resistant to breakage when flexed repeatedly, making them suitable for applications where the cable may need to bend or move.
7. Secure Connection: The JST XH connector ensures a secure and reliable electrical connection, minimizing the risk of signal interference or disconnection.
8. Versatility: This connector is versatile and can be used in various electronic applications, including connecting sensors, displays, motors, and other components to microcontrollers or control boards.
9. Length Options: Depending on the manufacturer, these cables may be available in various lengths to accommodate different project requirements.

In summary, the 7 Pin JST XH 2.54mm Pitch Plug with cable is a convenient and versatile connector assembly used in electronics and electrical projects. Its standard pitch, color-coded wires, and secure connection make it a popular choice for interfacing components in a wide range of applications.

Applications:

1. AC power supply to PCs and lab equipment.
2. Also used in CCTV connections, pick-ups, etc.

Package Includes:

1× 7 Pin JST XH 2.54mm Pitch Plug with cable
