This is a 7 Pin JST XH with Cable. It is a multipurpose cable. The length of the cable is 22cm. The crimp-style connector was developed based on the high reliability and versatility of the connectors. These wire-to-board connectors are typically used to bring power to a PC board.
Applications:
- AC power supply to PCs and lab equipment.
- Also used in CCTV connections, pick-ups, etc.
Features:
- Use of electrical fire retardant material.
- Solid and durable.
- Safe and easy to install.
Package Includes:
1× Balance Lead 7 Pin Replacement Cable 6S
| Specification | Details |
| Connector Type | JST XH |
| Number of Pins | 7 |
| Pitch | 2.54 mm |
| Connector Gender | Male (Plug) and Female (Socket) |
| Cable Length | Variable (commonly 150mm, 300mm) |
| Cable Type | UL1007 26AWG Stranded Wire |
| Voltage Rating | 250V AC/DC |
| Current Rating | 3A per pin |
| Insulation Resistance | 1000MΩ min. |
| Contact Resistance | 10mΩ max. |
| Wire Insulation Material | PVC |
| Operating Temperature | -25°C to +85°C |
| Housing Material | Nylon 66 UL94V-0 |
| Contact Material | Copper Alloy |
| Plating | Tin-plated |
